High Capacity SiC Carbide Graphite Crucible With Pouring Nozzle for High Temperature Resistance and Non-Ferrous Metal Melting
Product Details:
| Place of Origin: | China |
| Brand Name: | Baidun/J&J |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1PC |
|---|---|
| Price: | negotiate |
| Packaging Details: | Export Wooden Packing |
| Payment Terms: | L/C,D/A,D/P,T/T |
| Supply Ability: | 100pcs+ |
|
Detail Information |
|||
| Style: | Crucible With Pouring Nozzle | Application: | Melting And Casting Of Non-ferrous Metals |
|---|---|---|---|
| Surface Finish: | Smooth | Country Of Origin: | China |
| Material: | Silicon Carbide And Graphite | Shape: | Cylindrical |
| Corrosion Resistance: | Good | Thermal Conductivity: | High |
| Density: | 2.21-2.25 G/cm3 | ||
| Highlight: | Graphite Crucible Pouring Nozzle,High Capacity SiC Carbide Graphite Crucible |
||
Product Description
SiC Carbide Graphite Crucible With Pouring Nozzle High Capacity High Temperature Resistance Capacity 5kg-1000kg
Product Attributes
| Attribute | Value |
|---|---|
| Style | Crucible with Pouring Nozzle |
| Application | Melting and casting of non-ferrous metals |
| Surface Finish | Smooth |
| Country Of Origin | China |
| Material | Silicon Carbide and Graphite |
| Shape | Cylindrical |
| Corrosion Resistance | Good |
| Thermal Conductivity | High |
| Density | 2.21-2.25 g/cm3 |
Product Description
The J&J/Baidun Ladle with Pouring Spout Crucible is a versatile product suitable for various melting and casting applications. With a capacity ranging from 5kg to 1000kg, this crucible is designed to meet diverse operational needs in non-ferrous metal processing.
Key Features
- Longer Crucible Life: Reduced replacement frequency and downtime
- Increased Productivity: Faster melting and safer, easier pouring
- Improved Metal Yield & Quality: Cleaner transfers and less oxidation loss
- Cost Efficiency: Lower energy consumption and reduced operational costs per melt
- Enhanced Safety: Ergonomic pouring design minimizes operator risk
Upgrade your melting operation with the efficiency, durability, and precision of the Baidun Silicon Carbide Graphite Crucible with Pouring Nozzle - the intelligent choice for demanding non-ferrous metal applications.
Technical Specifications
| Name | SiC Graphite Crucible with Pouring Nozzle | Category | Isostaic Graphite Crucible |
|---|---|---|---|
| Material | Silicon Carbide And Graphite | Brand | Baidun/J&J |
| Place of Origin | ShanDong, China | Application | Melting And Holding Of Non-ferrous Metals |
| Applicable target | Oil Furnace, Gas Furnace, Coal Furnace, Flame Furnace, Electric Furnace | Style | Crucible with Pouring Nozzle |
| Maximum working Temperature | 1600℃ | Melting Metal | Non-ferrous metals |
Chemical Composition
| Items | UNIT | Value |
|---|---|---|
| Carbon | % | 36~40 |
| Sic | % | 26~30 |
| SiO2 | % | 14~18 |
| Si | % | 2~5 |
| Al2O3 | % | 8~10 |
| Na2O, K2O, Fe2O3, B2O3 & others | % | 2~4 |
The integrated pouring nozzle transforms a standard crucible into a unified pouring system, enhancing metallurgical quality through controlled metal transfer while reducing operator exposure to molten metal. Built to endure the thermal and mechanical stresses of industrial foundries, it delivers unmatched reliability for high-volume non-ferrous melting and casting.
Applications
These crucibles can be used for resistance furnace, induction furnace, biological particles furnace, gas furnace, coke oven, furnace oil, and gas furnace to melt gold, silver, copper, aluminum, tin, lead, zinc and other nonferrous metals, and various non-ferrous alloys.
Manufacturer Information
Qingdao Baidun Special Ceramics Technology Co., LTD. is located in the SCO Demonstration Area, Qingdao, China. With a registered capital of 100 million RMB and covering an area of 100,000㎡, Baidun specializes in the manufacture of crucibles for non-ferrous metal smelting, refractory products for continuous casting and alumina grinding ball.
With many years of research and field tests, Baidun has developed silicon carbide graphite crucibles which have characteristics of high oxidation resistance, high thermal conductivity, long service life, and low energy consumption. Third-party professional institutions have selected Baidun as the champion crucible brand in Chinese die-casting industry for many years since 2016.
Packaging & Shipping
Packing: Use professional export packaging, wooden box or wooden box packaging, cardboard, carton, ton bag, or packaging according to customer requirements.
Delivery time: 10-45 days after confirming the order, the specific delivery date should be determined according to the order quantity.
Frequently Asked Questions
Q: What is the brand name of the Conventional Type Crucible?
A: The brand name is J&J/Baidun.
Q: Where is the Conventional Type Crucible manufactured?
A: The Conventional Type Crucible is manufactured in Qingdao, China.
Q: What is the minimum order quantity for the Conventional Type Crucible?
A: The minimum order quantity is 1pc.
Q: What are the packaging details for the Conventional Type Crucible?
A: The packaging details include wooden cases.
Q: What are the accepted payment terms for purchasing the Conventional Type Crucible?
A: The accepted payment terms are TT/DP/LC.
