Non-Ferrous Metal Melting and Casting with Baidun SiC Graphite Crucible for Thermal Efficiency and Operational Convenience
Product Details:
| Place of Origin: | China |
| Brand Name: | Baidun/J&J |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1PC |
|---|---|
| Price: | negotiate |
| Packaging Details: | Export Wooden Packing |
| Payment Terms: | L/C,D/A,D/P,T/T |
| Supply Ability: | 100pcs+ |
|
Detail Information |
|||
| Style: | Conventional Type Crucible | Application: | Melting And Casting Of Non-ferrous Metals |
|---|---|---|---|
| Surface Finish: | Smooth | Country Of Origin: | China |
| Material: | Silicon Carbide And Graphite | Shape: | Cylindrical |
| Corrosion Resistance: | Good | Thermal Conductivity: | High |
| Density: | 2.21-2.25 G/cm3 | ||
| Highlight: | Operational Convenience SiC Graphite Crucible,Thermal Efficiency SiC Graphite Crucible |
||
Product Description
| Attribute | Value |
|---|---|
| Style | Conventional type Crucible |
| Application | Melting and casting of non-ferrous metals |
| Surface Finish | Smooth |
| Country Of Origin | China |
| Material | Silicon Carbide and Graphite |
| Shape | Cylindrical |
| Corrosion Resistance | Good |
| Thermal Conductivity | High |
| Density | 2.21-2.25 g/cm3 |
The Baidun Silicon Carbide Graphite Crucible is engineered for high-performance melting and handling of non-ferrous metals such as aluminum, copper, brass, bronze, zinc, and precious metals. Combining advanced materials with intelligent design, it delivers exceptional durability, thermal efficiency, and operational convenience for foundries, jewelers, and metal recyclers.
- Exceptional Temperature Resistance: Withstands continuous operation up to 1600°C (2912°F), providing a significant safety margin above copper's melting point (~1085°C).
- Superior Thermal Shock Resistance: The SiC structure excels at resisting cracks from rapid temperature swings.
- High Thermal Conductivity & Rapid Melting: Graphite enables efficient heat transfer, significantly accelerating melt times.
- Excellent Oxidation Resistance: SiC forms a protective silica layer, drastically slowing degradation.
- Extended Service Life: Resists erosion from molten metals/slag and withstands thermal cycling fatigue.
- Chemical Inertness: Maintains integrity against common metal fluxes and oxides.
| Name | SiC Graphite Crucible For Copper Melting | Category | Isostaic Graphite Crucible |
|---|---|---|---|
| Material | Silicon Carbide And Graphite | Brand | Baidun/J&J |
| Place of Origin | ShanDong, China | Application | Melting And Holding Of Non-ferrous Metals |
| Applicable target | Oil Furnace, Gas Furnace, Coal Furnace, Flame Furnace, Electric Furnace | Style | Conventional Type Crucible |
| Maximum working Temperature | 1600℃ | Melting Metal | Non-ferrous metals |
| Items | UNIT | Value |
|---|---|---|
| Carbon | % | 36~40 |
| Sic | % | 26~30 |
| SiO2 | % | 14~18 |
| Si | % | 2~5 |
| Al2O3 | % | 8~10 |
| Na2O, K2O, Fe2O3, B2O3 & others | % | 2~4 |
- Automated Copper/Brass Casting Lines
- High-Frequency Tilting Furnace Systems
- Precision Jewelry/Art Casting
- Copper Rotor/Component Production
- Recycling Operations with Direct Pour
| Metal Type | Max Temp (°C) | Performance Benefit |
|---|---|---|
| Gold/Silver | 1,100 | Zero contamination • Minimal precious metal loss |
| Copper/Bronze | 1,300 | Resistance to CuO slag erosion |
| Aluminum Alloys | 900 | Prevents Al penetration • Flux corrosion resistance |
| Zinc/Tin/Lead | 750 | Longevity in low-melt applications |
Qingdao Baidun Special Ceramics Technology Co., LTD. is located in the SCO Demonstration Area, Qingdao, China. The company specializes in the manufacture of crucibles for non-ferrous metal smelting, refractory products for continuous casting and alumina grinding ball. With a registered capital of 100 million RMB and covering an area of 100,000㎡, Qingdao Baidun operates two brands, "Baidun" and "J&J", serving Chinese and overseas markets respectively.
Qingdao Baidun is one of the largest crucible manufacturers in China that uses isostatic pressing technology to produce silicon carbide graphite crucibles and clay graphite crucibles. The company's technical team has developed crucibles with characteristics of high oxidation resistance, high thermal conductivity, long service life, and low energy consumption.
J&J/Baidun Crucible is a top-quality product made in China, known for its high temperature resistance, chemical resistance, and durability. Composed of high pure materials such as SiC and clay, this crucible is designed for laboratory applications requiring reliable performance under extreme conditions.
Packing: Professional export packaging, wooden box or wooden box packaging, cardboard, carton, ton bag, or packaging according to customer requirements.
Delivery time: 10-45 days after confirming the order, the specific delivery date should be determined according to the order quantity.
A: The brand name is J&J/Baidun.
A: The Conventional Type Crucible is manufactured in Qingdao, China.
A: The minimum order quantity is 1pc.
A: The packaging details include wooden cases.
A: The accepted payment terms are TT/DP/LC.
